99005 series

Article: 00003363

Polyamide hose / for fuel / for vacuum / for automotive applications

-
Made of polyamide (PA)
-
Color black (red, blue, green, yellow, natural, brown, orange a
nd
grey: specify when placing order; subject to extra charge)
-
External calibration; for use with Eisele plug connectors
-
Temperature range -60 to +100 °C
-
Operating pressure = burst pressure: safety (common factor 2 to
3)
-
Suitable for vacuum
-
Free of PWIS and halogen
-
Suitable for fuel
-
For automotive industry according to DIN 73378

Specifications

  • Material: polyamide
  • Media: for fuel
  • Applications: for vacuum, for automotive applications
  • Other characteristics: halogen-free
  • Inner diameter: Min.: 2 mm
  • Outer diameter: Min.: 4 mm
  • Pressure: Min.: 49 bar (710.68 psi)
  • Temperature: Min.: -60 °C (-76 °F)
