Colorimeters

Eoptis Srl

  • In-line colorimeter / reflectance / automatic / with LED light
  • In-line colorimeter / reflectance / automatic / with LED light
  • In-line colorimeter / reflectance / automatic / with LED light
  • In-line colorimeter / reflectance / automatic / with LED light

CLM series

Article: 00026377

In-line colorimeter / reflectance / automatic / with LED light

EOPTIS offers a device for touchless colorimetric measurement, able to provide accurate and repeatable information about the colour of the surface under inspection.
CLM-195 is a rugged system, designed to be installed in production lines and suited to 24/7 operations in industrial environment. Colour measurements can be performed on the surface of a wide range of matte and glossy materials, thanks to a (45°c:0°) measurement geometry and the very uniform illumination provided by integrated LEDs.

Measured data (last valid measure or moving average) can be analyzed on-board, to have an immediate pass/fail result, that is also made available on the digital I/Os. Data can also be sent to a remote calculator for deeper analysis, storage (datalogger feature) or for report generation.

The CLM-195 Colorimeter features two modes of operation:
- FINE mode, that provides absolute colorimetric data in the CIELAB color space with typical repeatability of 0.03 DE*ab
- FAST mode, that delivers differential colorimetric data at a measurement rate up to 1 data per second.

Standard colour database is encoded in the software provided with the product while a custom or application-specific colour database can be added by the user or with Eoptis's support on request. A NIST-traceable factory calibration service and software interface and report template customisation services are available on request.

Specifications

  • Mounting: in-line
  • Specifications: reflectance, automatic, with LED light, high-precision, for tomato products, peanut butter, for baked products, roasted coffee
  • Technical applications: for color measurement, for surface inspection, for analysis of skin color and pigmentation
  • Domain: for the food industry, for the petroleum industry

Other items

In this category | In this category, (Eoptis Srl)
