SF/C

Article: 00053093

Calorimetric flow sensor / thermal / air

The SF/C flow / temperature sensor measures the airflow rate from 0-20 m/s and optional the temperature from 0...+50°C of the ambient air. The transducer converts the measured values into a linear output signal 0-10 V or 4-20 mA. The airflow sensor works on the calorimetric measuring principle and provides 5 different measurement range scalings (0-3 m/s, 0-5 m/s, 0-10 m/s, 0-15 m/s, 0-20 m/s) which can be adjusted by innovative DIP switch technology. With the optional LCD display the measured values ??can be displayed locally on the duct. The flow sensor is also with a change-over contact available. The switching point can be adjusted on the board within the selected scale via a potentiometer and is visualized by a LED segment display.

Specifications

  • Technology: calorimetric, thermal
  • Applications: air
