max. 9 kW | tm 20

Article: 00130109

CNC automatic lathe / universal / 2-axis / double-spindle

cam-controlled twin spindle
automatic lathe for second operation

Based on the tm 10 this machine is equipped
with a second main spindle. The range of
application is extended for change over,
two-fold or double-sided machining, front and
back side processing but also successive
turning operation are possible. The use
of two feeding systems with simultaneous
production double the output compared to
the single spindle technology.

- drives from 7,5 to 9 KW
- maintenance-free precision
? spindle bearings
- SPS control for master functions
- output up to 70 pieces per minute

interchangeable chucking devices
- pull collet and push collet
- overhead chuck
- power-operated lathe arbor
- special chucking devices possible

interchangeable tool carriers
- radial cut off slides and cross sildes
- cross slides
- spindle sleeve tools for drilling operation

optional equipment
- spindle positioning
- two-machine operation
- turning station, return station

Specifications

  • Control type: CNC
  • Spindle orientation: universal
  • Number of axes: 2-axis
  • Number of spindles/turrets: two-spindle
