Compression load cells

HAEHNE

  • Tension force sensor / strain gauge / for wire rope tension / for cables

ZAD

Article: 00027415

Tension force sensor / strain gauge / for wire rope tension / for cables

Tension force sensors of the type ZAD were specifically developed
for direct measurement of forces acting in cables, wires, ropes, or
tapes. They can best be installed in places where the design of
the machine already requires the use of deflection rollers
or guide rollers.
This is e. g. the case in situations such as
- cable making machines
- stranding machines
- foil capacitor manufacturing
- label printing machinery etc.
When using an application of force transmission screw instead of
a roll the tension sensor ZAD may be used as a compression load
cell. The axial cable entry allows in most cases a simple installation
on the machine. Mechanical stops limit the measurement path and
serve as overload protection.
The sensor is designed according to the double beam principle.
This results in high precision measurement even in off center load
situations. Strain gauges applied to the active surfaces of the cantilever
beam measure the acting forces.
The strain gauge bridge is supplied with stabilized DC voltage
from a strain gauge amplifier of the HAEHNE program for further
processing of the measuring signals.

Specifications

  • Type: tension
  • Technology: strain gauge
  • Applications: for wire rope tension, for cables
  • Other characteristics: stainless steel
  • Rated force: Min.: 10 N
