Volumetric Flow Meters

Schiltknecht Messtechnik

  • Positive displacement flow meter / for flue gas / in-line

STEMO1

Article: 00140982

Positive displacement flow meter / for flue gas / in-line

The volume flow measurement is necessary in addition to the concentration measurement (e.g. % CO2/m3) to measure the exact volume of noxis gases.
This is the volume flow measurement of air in the stack so that the volume of air (in m3) that flows through the chimney cross-section per unit of time (in s or h) is to be measured.

The measuring system is installed preferably at the top of the stack where the exhaust air enters the atmosphere. The STEMO1 stack monitoring system provides a high-precision volume flow measuring instrument the measuring uncertainty of which can be reduced to considerably below 1 %.
Its accuracy is traceable, i.e. EN ISO 15267 and the new edition of the EN ISO 14181 standard are optimally satisfied. The necessary approval procedures are being prepared.

Robust, weather-proof sensor mechanics without moving parts
Grid measurement of the volume flow with a high accuracy of under 1 %
Simple installation for continuous use
Can also be used as a mobile unit

Specifications

  • Technology: positive displacement
  • Fluid: for flue gas
  • Mounting: in-line
