Axial Fans

Cyclonedynamics Electronics Co

  • Axial fan / cooling / EC / AC
  • Axial fan / cooling / EC / AC
  • Axial fan / cooling / EC / AC

UAB series

Article: 00009184

Axial fan / cooling / EC / AC

Permanent magnet motors running on high voltage direct current (DC) electricity with built in AC to DC conversion allowing them to run direct from single phase or three phase mains supplies. There are several suppliers of such motors.

Outline
The GreenTech, CCS is applied to Mini EC Fan.
Mini EC Fan enables to control RPM without any SMPS with the power supply extra to totally replace AC fan.
Compare to traditional AC fan, 6cm 8cm 9cm12cm17cm 20cm EC Fan allows you to optimize your cooling system for ultimate energy efficiency, potentially reducing energy usage by up to 70-80%.
The working range of power input for VAC & VDC is widely applicable to both AC input and DC input, AC 80 - 308V, DC 10V - 450V.
They are all constant speed.
(The working range of ACDC decided on the fuse inside. Also, kindly contact our sales for the higher range & special specification)

Power Factor PFC
When it comes to Full Speed, the power factor PFC > 0.9 which is especially suitable for the fan tray. Mini EC fan could be instead of AC fan tray, rack fan and part of DC fan tray without PFC circuits more in accordance with the standard of EU EN61000-3-2.
All switches inside of PSU for the output power factor that is > 75W needs at least a function of modification on passive PFC. Meanwhile, the standard of the switch for 80 PLUS claims the factor of power reaching the level of 0.9 in any case.

Specifications

  • Configuration: axial
  • Function: cooling
  • Other characteristics: EC, AC, DC
  • Air flow: Min.: 99 ft³/min (2.8 m³/min)
  • Mounting: for integration
