NW 300

Article: 00016037

Double-roll lump breaker / for grain / horizontal

LUMP BREAKER - ROLLER CRUSHER

KEY FEATURES

ATEX conformity

GMP conformity

CIP capability

Maximum capacity: 27 t/h¹

Maximum feed lump size: 280 mm¹ (11")

Range of final grain size: 0.5 mm to 15 mm¹ (0.02" to 0.6")

Sieve-free functional principle

Low wear-out and maintenance

Variable roller speed, capacity and breaking slit

Material in contact with product: 1.4462 (AISI 318LN); 1.4404 (AISI 316L)

Ripping effect through adjustable roller speed differential

Roller extraction mechanism for revision and cleaning access

10 bar pressure-shock resistant when operated in pneumatic line

Connectivity with flanges according DIN 24154 T2 NW 300 mm (12")

Optional layout for increased operating temperatures exceeding 70°C

Specifications

  • Technology: double-roll
  • Material: for grain
  • Orientation: horizontal
  • Output: 27 t/h (16.53 lb/s)
