Laser Cutting Laser Machining

Perfect Laser Co

  • CO2 laser cutting machine / for acrylics / wood / stainless steel
  • CO2 laser cutting machine / for acrylics / wood / stainless steel
  • CO2 laser cutting machine / for acrylics / wood / stainless steel
  • CO2 laser cutting machine / for acrylics / wood / stainless steel
  • CO2 laser cutting machine / for acrylics / wood / stainless steel
  • CO2 laser cutting machine / for acrylics / wood / stainless steel
  • CO2 laser cutting machine / for acrylics / wood / stainless steel

PEDK-130250M

Article: 00072497

CO2 laser cutting machine / for acrylics / wood / stainless steel

product advantages
- InPack Technology?: Protects the laser components for high-quality cutting results.
- All-round access: The freely-accessible processing area can be accessed from all sides.
- Adaptable: A wide range of processing tables and accessories.

1.Application: Laser Cutting
Available Materials: acrylic, leather, MDF, metal, plastic, Plexiglas, plywood, rubber, wood,etc.

2.Technical Data
model:PEDK-130250
working area:1300*2500mm
laser type:Hermetic and Detached Co2 Laser Tube
engraving speed:1-60000mm/min
cutting speed:1-10000mm/min
repeat location accuracy:± 0.0125mm
laser power controlling:1-100% manual adjustment and software controlling
voltage:220V(±10%) 50Hz
cooling mode:water cooling and protect system
cutting platform:professional thickening strip or honeycomb work table
guarantee:12 month guarantee period

3.Product Features
1)Advanced LCD Touch Screen+ USB port+ DSP Offline Control, not only work without computer, but also connect to U disk, USB communication.

2)LCD Control System own 128M Big Memory, storing files in the machine for engraving and cutting, compatible with AutoCAD, CorelDraw, Photoshop and some other kinds of graph disposal software.

3)Imported high precision linear guide rail and professional optical system, dustproof and lubricate, improving the engraving quality and prolong machine lifetime.

4)Special Front and back runningthrough design, the unique door for the limitless engraved materials through.

5)Water cooling system with alarm protection function, adopt CW-3000 Water Chiller with temperature display, which avoid over burning,protect the water circulation from electricity-off.

Specifications

  • Technology: CO2 laser
  • Treated material: stainless steel, wood, for acrylics
  • Structure: gantry type
  • Operation: fully-automatic
  • Associated function: profiling
  • Applications: for metal sheets, for large parts
  • Other characteristics: CE, 1-spindle
  • Cutting speed: Min.: 1 mm/min (0 in/s)
  • Laser power: Min.: 150 W (0.2 hp)
